Enclosure Project Resume

C175-16 3000KW ENCLOSURE PACKAGE

Caterpillar C175-16 Standby Unit in one of our Sound Attenuated Enclosures. This unit has a Level 3 sound package, roof mounted exhaust/catalyst room, separate radiator room, ventilation fans for engine room, 12,000 gallon fuel tank, 300 gallon daytank with fuel supply and fuel return pump systems, bi-fuel gas train, as well as many AC & DC electrical options. The enclosure is painted Tan Smooth Glossy.

3516C-HD 2500KW ENCLOSURE PACKAGE

Caterpillar 3516C-HD Standby Unit in one of our Sound Attenuated Enclosures. This unit has a Level 2 sound package, roof mounted radiator room, ATAAC water pump, ventilation fans for engine room, 500 gallon daytank with supply and return pump system, as well as many AC & DC electrical options. The enclosure is painted Tan Smooth Glossy.

SAVANNAH PORTS AUTHORITY

(20) C-15 Caterpillar Generators supplied to the Port of Savannah (Georgia) to power their field RTG (Rubber Tyred Gantry) cranes for loading and off loading merchandise from incoming ships. Special designs were required to insure that the envelope did not exceed the space requirements between the wheel housings.

C27 800KW ENCLOSURE PACKAGE

Caterpillar C27 Standby Unit in one of our Weather Protective Enclosures. This unit has a 48 hour tank with NFPA-30 tank options, and a basic AC & DC electrical package.

C2I LANDFILL

Caterpillar G3520C landfill gas unit in Sound Attenuated Enclosure. Unit contains all components necessary for this prime power application: CCV System, Solberg System, and a customized ventilation fan to help cool the engine. Switchgear is also housed inside its own climate controlled room that is isolated from the engine compartment.

3512C 1500KW ENCLOSURE PACKAGE 3

Caterpillar 3512C Standby Unit in one of our Sound Attenuated Enclosures. This unit has a level 3 sound package, best battery selector system, day-tank with fuel supply and return pump system, exterior wall mounted ladder, motorized intake & discharge louvers, as well as many AC & DC electrical options.

3512C 1500KW ENCLOSURE PACKAGE

Caterpillar 3512C Standby Unit in one of our Sound Attenuated Enclosures. This unit has a Level 2 sound package, 24 hour tank, internally mounted NGR, and basic AC & DC electrical package. The enclosure is painted Bengal Dark Gray.

C32 1000KW ENCLOSURE PACKAGE

Caterpillar C32 Standby Unit in one of our Sound Attenuated Enclosures. This unit has a level 2 sound package, 5000 Gallon tank, fuel supply & fuel return pump system, and a basic AC & DC electrical package. The enclosure is painted Bengal Dark Gray.

JACKSON EMC

CAT C32 Weather proof enclosure with transfer witch inside of unit. Emergency side of the transfer switch was completely done when the unit arrived in the field.

3516C 2000KW ENCLOSURE PACKAGE

Caterpillar 3516C Standby Unit in one of our Weather Protective Enclosures. This unit has a level 1 sound package, 12 hour tank, fuel supply & fuel return pump system, and a basic AC & DC electrical package. The enclosure is painted Bengal Dark Gray.

3512C 1500KW ENCLOSURE PACKAGE 2

Caterpillar 3512C Standby Unit in one of our Weather Protective Enclosures. This unit has a 2500 gallon tank, Skin-Tight interior, and a basic AC & DC electrical package. The enclosure is painted Polar White.

NURSING HOME

Custom tanks can be built to meet any fuel requirements necessary. CAT packages are mounted and fuel lines are plumbed so that the unit is ready to go when it arrives on the job-site.

ROGERS

CAT 3516 sound attenuated package with a snow hood on the discharge. YES can custom design packages to meet any requirements by the customer.

3516 UP-FIT

YES can also customize open units. These units have their own fuel system, best battery system, and dual jacket water heaters.

NOISETTE

Before and after shot of a replacement that was done totally in the field. A very old CAT package was replaced with a drop over enclosure.
